• iABS 2S/2M to 4S/3M Premium
• Pin to Pin : 40" (1-5/8")
• Optional Air pin puller available
• Medium Arc. 355 Leaf spring, 1-1/4" Spring seat, 7/8" Bottom plate (5"OD)
• 19" Adjuster & Fixed torque arm
• 20L Aluminium Tank
• XS7 22XLT equipped ema24 regen system
• synchronized dual-piston 5 gear mechanism caliper
• Continuous Wear Sensor ready (CWS)
• Visual wear indicators on calipers and rotors
• Copper-Free High-performance brake pads, 2025 compliant
• Turbo-Flo, 430mm, Iron Rotor
• High-perform. piston brake actuator / • 20K Brake rating
• 95% efficiency & high electric power density
• 8.8kW rated power per tandem axles @60mph
• Light weight system - 32lbs per tandem axles
• Easy factory install, retrofittable system
Converter
• High voltage output
• Dual stage circuit design - Power Factor Correction(PFC) & Buck Converter
• Self overload protection design / 10"X10"X3", 24lbs compact design
Inverter
• Customizable AC power output for eTRU / 9"X9"X5", 25lbs slim fit design
RCU (Regen ECU)
• Optimized central control system with diagnosis UI / 5"X4"X2", 6lbs
• Communication Module ECU (CME)
• Bluetooth, GPS enable
• ATIS wireless thermal Event monitoring system
• TireView TPMS
