Specification Trailer 48' Dryvan trailier • MFG, Hyundai Translead
• MFG, date - 11/2023
• VIN. 3H3V482KXRJ242090
• GVWR 68,000lbs / GAWR 20,000lbs Axle System HDNABI Axle assembly • 77.5" seamless 5"O.D., 25K, Parallel spindle
• XS7 22XLT, synchronized dual-piston 5 gear mechanism caliper
• Continuous Wear Sensor ready (CWS)
• Visual wear indicators on calipers and rotors
• Copper-Free High-performance brake pads, 2025 compliant
• Turbo-Flo, 430mm, Iron Rotor
• High-perform. piston brake actuator
• 20K Brake rating Regen system HDNABI EMA24-LAC Regen system • Permanent Magnet Synchronous Generator (PMSG)
• 95% efficiency & high electric power density
• 8.8kW rated power per tandem axles @60mph
• Light weight system - 32lbs per tandem axles
• Easy factory install, retrofitable system
CONVERTER • Low voltage output
• Dual stage circuit design - Power Factor Correction(PFC) & Buck Converter
• Embedded self-overload protection
• 10"X10"X3", 24lbs compact package RCU (Regen ECU) • Optimized central control system with diagnosis UI
• 5"X4"X2", 6lbs small formfactor Wheelend SKF • X-Treme Scotseal, bearing, black zytel hubcap PSI system • Tire inflation system Liftgate Anthony • 4,500lbs lifting capacity
• 84"X90" Aluminum platform
• Hybrid GLR Ride
• Centralized Hydraulic System Exterior Ridge • Trailer Helmet
• GreenWing Side Skirt, 65lbs
• TransCore Roll-up Door, 96lbs
